Product Description

Basic Information

Model NO.Security Man 5

Base TypeE26

Irradiated Area≥30m²

Input VoltageAC200-250V / DC12-48V

Power30W - 240W

Color Temperature2000K-7000K

LED Chips BrandCREE/Lumen/Atmospherics

CertificationATEX, IECEx, CE, RoHS, UL844

CRI>80ra

MaterialAluminum + Stainless Steel + Tempered Glass

Luminous Flux140lm/W

IP RateIP66 / IK10

Warranty5 Years

Lifespan>50,000 hours

Working Temp-40° ~ +60°C

PF0.95

Key Features

★Working Temperature: -40°C ~ +55°C.

★High quality SMT LED, heavy-duty and high impact resistance.

★Replaceable LED board and drivers.

★Integrated junction box for driver.

★Dimmable and battery back up function available.

★Marine rating powder coated finish treatment.

★Various installation ways for different applications.

★Glass lens or polycarbonate lens to make different beam angles.

Characteristic & Certifications

Marking ATEX: II 2 G Ex eb mb IIC T6...T4 Gb / II 2 D Ex tb IIIC T80°C...T100°C Db IP66

Marking IECEx: Ex eb mb IIC T6...T4 Gb / Ex tb IIIC T80°C...T100°C Db IP66

Marking UL844: Class I, Div 2; Class II, Div 1 & 2; Class III

Marine Marking: UL 1598, UL 1598A, ABS

Specifications

Product Number	Wattage	Color Temp	Voltage	Lumens	Warranty	CRI	Emergency Time
EX-30W/50W/60W	30W/50W/60W	2200K-7000K	AC/DC Multi	4200-8400	5 Years	70	3 Hours
EX-80W/100W	80W/100W	2200K-7000K	AC/DC Multi	11200-14000	5 Years	70	3 Hours
EX-150W/180W/200W	150W-200W	2200K-7000K	AC/DC Multi	21000-28000	5 Years	70	3 Hours
EX-240W	240W	2200K-7000K	AC/DC Multi	33600	5 Years	70	3 Hours

Light Distribution & Dimension

Mounting Options

Applications

Oil and Gas Industry

• All petroleum production and refining, loading, transportation, storage and retail. LNG industry.

Chemical Industry

• All types of paint facilities, chemical production and storage.

Ocean, Marine & Aerospace

• Ocean platforms, vessel operations, aerospace clean rooms and production facilities.

Metal Treatment

• Steel and aluminum factories, metal smelting, foundry and fabrication.

Packaging Info

Quantity/Carton	Packing Size (mm)	N.W (KG)	G.W (KG)
1 Piece	460490290	12.5	15

FAQ

What is the IP and IK rating for this light?

The flood light features an IP66 dustproof and waterproof rating, along with an IK10 impact resistance rating.

Does this light support emergency mode?

Yes, there is an emergency backup function available with an emergency time of up to 3 hours.

What is the warranty period?

We provide a 5-year warranty for this professional-grade explosion-proof LED lighting series.

What certifications are held by this product?

The product is certified by ATEX, IECEx, UL844 (North American), CE, RoHS, and various marine ratings like ABS.

Can the LED boards or drivers be replaced?

Yes, the LED boards and drivers are replaceable, ensuring easy maintenance and a longer service life.

What industries is this lighting suitable for?

It is ideal for Oil and Gas, Chemical, Metal smelting, Ocean platforms, and Food/Alcohol processing industries.
